Isuzu 6BG1 Engine
The Isuzu 6BG1 diesel engine provides industry leading performance and holds up to the Isuzu mantra of "Performance that goes to work". This engine is offered in a 154 HP, constant speed rating option along with a 174 HP, variable speed rating option.
Features
- Displacement: 4.3 L – 6.5 L
- Turbo charged
- Fuel consumption: .355 LB/HP-HR
- Flywheel housing: SAE 3
- Electric self-priming fuel lift pump
- 12V and 24V available
- Glow plug starting aid
- High angularity oil pan
- 500-hour service intervals
- 5-year / 5,000-hour limited warranty*
Isuzu 6BG1 Engine Models
| 6BG1 (154 HP) | 6BG1 (174 HP) | |
| Hp | 154 | 174 |
| kW | 114.8 | 129.8 |
| RPMs | 2500 | 2500 |
| Liters | 6.5 | 6.5 |
| Cubic Inches | 396.7 | 396.7 |
| Dry Weight | 1089 lbs | 1089 lbs |
| Cylinders | 6 | 6 |
| Cycle | 4 Stroke | 4 Stroke |
| Engine Rating | Constant Speed | Constant Speed |
| Emissions |
US EPA Tier 2 |
US EPA Tier 2 |
